产品介绍

■Transmission Frequency:ISM 2,400~2,483 MHz

■Transmission Power:10mW/CE; 2mW/FCC

■Operating Frequency:2414MHz;2432MHz;2450MHz;2468MHz

■Unobstructed Effective Range:100m(Min.)

■Modulation Mode:FM

■Operating Temperature:-10 ~ +50(Degree C) / +14~ +122(Degree F)

■Storage Temperature:-20 ~ +60(Degree C) / -4 ~ +140(Degree F)

■Operating Humidity:≤85%RH



CAMERA

■Imaging Sensor Type:CCD

■Picture Total Pixels:PAL:628×582 Pixels;
                        NTSC: 510×492 Pixels

■Horizontal Resolution:420 TV Lines

■View Angle:PAL:60°; NTSC:40°

■Minimum Illumination:0Lux

■Night Vision Range:7m

■BandWidth:25M

■Consumption Current:95mA(IR OFF) (Max.)&170mA(IR ON)(Max.)

■Power Supply:DC +12V

■Dimensions(W×D×H):45*78*83mm

■Weight:217 g



Receiver

■Antenna:50 ohm SMA

■Receiving Sensitivity:≤-85dBm

■Video Output Signal Level:1.1Vpp±0.2Vpp@75 ohm, S/N >38dM

■Audio Output Signal Level:3.0Vpp±1Vpp@600 ohm

■Consumption Current:190mA(Max.)

■Power Supply:DC +8V

■Dimensions(W×D×H):16* 102 *80mm

■Weight:120 g
