System Capabilities
Allows Wi-Fi connection of iPad mini for downloads of Apps, audio content and certain upgrades.
Connects to compatible control systems via Wi-Fi for operating home automation systems
Supports iPad mini as a semi-permanent fixture in a modern and elegant manner.
Compatiable with the iPad mini and iPad mini with Retina.
Note: A relief cut is required to accommodate the apple connector. The cut can be made on either side of the mount. The location will be determined by the orientation of the iPad. Please reference the Cutout template under 慏ownloads? for more detailed information.
Dimensions (W x H x D):
9.56 inches (242.8 mm) x 7 inches (177.8 mm) x 2 inches (50.8 mm)
Cut-Out Dimensions (W x H):
8.83 inches (224.28 mm) x 6.44 inches (163.58 mm)
System Components
Mounting cradle assembly for semi-permanent fixture with magnetic bezel.
USB Power Electronics board with 2-pin connector
Power wall plate with 2-pin connector
Power supply
Depth from Fascia to Wall Surface: 0.18 inch (4.5 mm)
Weight: 1.75 pounds (793.7 g)
关于I-PORT
iPort, maker of the first in-wall music system for iPod, provides freedom from the constraints of headphones and miniaturized speaker systems. iPort is the first multiroom audio integration solution for iPod, making it possible to easily share music, videos, and photos throughout a home or commercial setting, and seamlessly integrating iPods and iPhones into virtually any entertainment system.
Patented iPort technology is suitable for a wide range of audio and audio-video system concepts, including highly customizable multiroom and whole-house layouts, multiroom AV receivers, single-room/zone connections, and more.
iPort is the innovation of Scott Struthers, co-founder of Sonance, developer of the first high fidelity in-wall speaker, and a founding member of CEDIA.
iPort is a registered trademark of Dana Innovations.
