MX400
Seven Effects Routing Options
The MX400 lets you switch effect routings automatically via front panel controls, so you don't have to spend time behind yoru rack changing cables to instantly re-purpose its four powerful processors.
From basc quad mono, to sterero to more complex dual stereo configurations, you can have 'em all at the twist of a knob.
Features
Also available: The MX400XL with balanced XLR inputs and outputs.
■ 17 legendary Lexicon® reverbs
■ Lexicon delays & modulation effects
■ dbx® compression and de-essing
■ Quad-processor design
■ 7 effect routing options
■ 99 Factory/99 user programs for Stereo mode
■ 99 Factory/99 user programs for Dual-Stereo mode
■ 25 Factory/25 user surround programs
■ USB Hardware Plug-In feature with
■ VST® and Audio Units plug-in software
■ MX-Edit™ Editor/Librarian software
■ Dual S/PDIF Digital Input/Output
■ 24 bit, 48kHz/44.1kHz sample rates
■ Large front panel LCD display
■ MIDI IN and THRU
■ 1/4 balanced/unbalanced TRS I/O
|
Analog Audio Inputs |
|
|
Connectors |
(4) 1/4 TRS balanced or unbalanced |
|
Impedance |
50k Ohms bal., 25k Ohms unbal. |
|
Input Level |
+4 dBu nominal, +24 dBu maxium 48kHz or 44.1kHz |
|
A/D Conversion |
24-bit, 48kHz 128 x oversampling |
|
Analog Audio Outputs |
|
|
Frequency Response |
10Hz - 20kHz +0 dB/-0.5 dB |
|
THD+N |
<0.0019% 10Hz - 20kHz |
|
Dynamic Range |
>109dB (A-weighted) A/A |
|
Crosstalk |
typical <-80 dB 20Hz - 20kHz |
|
Digital Input and Output |
|
|
Connectors |
Dual RCA phono (S/PDIF) |
|
Format |
S/PDIF 24-bit |
|
Sample Rate |
44.1 or 48kHz |
|
Frequency Response |
10Hz to 22kHz ±0.5 dB @ 48kHz |
|
Control Interface |
|
|
USB |
USB 1.0 for MX-EDITª Editor/Librarian and VSTª/Audio Units plug-ins |
|
MIDI |
In/Out 5-pin DIN |
|
Foot Pedal |
1/4 phone jack |
|
General |
|
|
Power |
117 VAC or 230 VAC, 18 Watts |
|
Size (W/H/D) |
19 x 1.75 x 7.25*/6.375 |
|
Weight |
5.8 lbs. (2.6 kg) |
