Features：
■ Advanced class D for high performance and compact size.
■ Perfect protection(Soft start, clip limiter, thermal limiter, power limiter, DC,VHF,AC, short-circuit).
■ High and rigid enclosure.
■ Binding post and Neutrik Speakon outputs.
■ Variable speed fan with low noise.
■ Input Sensitivity：0.775V
■ Signal\clip and limiter LED indicators to monitor performance.
■ Input Impedance: 10Kohms unbalanced,10Kohms balanced.
■ Power output(EIA 1KHZ 1% THD): 2Ω@2200W+2200W(TITAN2.22)
2Ω@2570W+2570W(TITAN2.26)
2Ω@3000W+3000W(TITAN2.30)
TITAN amplifier work mode of FM-PM modulate technology and original efficiency C improve technology. Make amplifier’s efficiency reach 96%,rate of distortion reach 0.02%. use spread spectrum technology to get less EMI, ordinary class D amplifier’s efficiency is less than 90%, TITAN amplifier provide speaker more strong power than ordinary analogy amplifier, and reduce more thermal loss,high efficiency means reduce more space, weight and power consumption of the equipment, the highest value of this technology is conversion efficiency, almost each output level is independent. Ordinary analogy amplifier only could run in optimal state when full power output, because the average power of standard music signal is less than 40% of it’s maximal level. In the situation of same volume, ordinary analogy amplifier easily to produce heat which more than 15 times of TITAN amplifier.
To avoid scaring people when there is big signal and current relay switch on, TITAN gradually turn to the volume of last setting when current relay switch on , on ordinary current relay working mode, there is signal voltage on each contact, so there is current when open or short, arcing will exist because of the voltage on the contact, and these arcing will produce impedance on the contacts, perfect damping factor and service life of the equipment will be reduced by this impedance.
