FEATURES:
■Compact size - up to 2400 watts in 2 rack spaces
■Professional quality performance - incorporates road-proven QSC designs
■High-current toroidal transformers for greater two-ohm power and low noise
■Independent user-defeatable clip limiters reduce distortion
■Selectable low-frequency filters (30 Hz or 50 Hz) protect speakers and increase headroom
■Balanced 1/4 (6.3mm) TRS, XLR and barrier strip inputs
■Binding post and Neutrik Speakon outputs
■Front mounted gain controls for easy access
■Signal and Clip LED indicators to monitor performance
■Independent DC and thermal overload protection on each channel automatically protects amplifier and speakers
■3-year warranty plus optional 3-year extended service contract
FTC 20 Hz - 20 kHz, 0.1% THD
EIA 1 kHz, 0.1% THD
185 W
200 W
FTC 20 Hz - 20 kHz, 0.1% THD
EIA 1 kHz, 0.1% THD
280 W
300 W
EIA 1 kHz, 1% THD
430 W
FTC 20 Hz - 20 kHz, 0.1% THD
EIA 1 kHz, 0.1% THD
530 W
600 W
EIA 1 kHz, 1% THD
830 W
1/8 power pink noise at 4 ohms *
20 Hz - 20 kHz: 10 dB below rated power
1.0 kHz and below: full rated power
Less than 0.03% THD, 4 and 8 ohms
Less than 0.03% THD, 4 and 8 ohms
-3 dB points: 5 Hz - 50 kHz
TRS tip and XLR (pin 2 positive)
Output: touch-proof binding posts and Neutrik® Speakon®
Rear: 10-position DIP switch
Signal: Yellow LED (1 per channel)
Clip: Red LED (1 per channel)
15.9 (40 cm) deep (rack mounting to rear support ears)
